Description

Gate Valves are Bi-directional Multi-Purpose Valvesused for Isolation services, they are available in various material of construction like Carbon Steel, Stainless Steel, Exotic Steel Material.

Gate Valves are available in various type depending on the Application used they are Wedge Gate Valve (API 600 & API6D), Through Conduit Gate Valve, Parallel Slide Gate Valves, Etc

Gate valves are used in many industrial applications including Petrochemical, Oil & Gas, Pipelines, Power, Tank Farms,Allied process and also services such as corrosive and cryogenic.


Social Media Share
. . . .
0/5 (0)

My Rating Form

Forged Steel Gate Valve (Ansi Classes 800/1500/2500) Construction
  • Size : ½” to 2”
  • Rating : ANSI Classes 800, 1500 & 2500
  • OS & Y type, Bolted Bonnet, Reduced Bore, Solid Wedge
  • Design Std: API 602/ ANSI B 16.34, Testing Std: API 598
  • Face to Face as per Manufacturer Standard
  • End Connection : Screwed NPT(F)/ Socket Weld Ends / Butt Weld Ends / RTJ
  • Hand Wheel
  • NACE as per MR-01-75
Others on Request
  • Full Bore Construction
  • Welded Bonnet
  • Locking Arrangement
  • High Temp./ Cryogenic Service
  • All Exotic Materials (Hastelloy/ Incoloy/ Super duplex)
Construction
  • Size: 2” to 48” (150# & 300#), 2” to 30” (600#) – Bolted Bonnet
  • Size: 2” to 24” (900# & 1500#), 2” to 12” (2500#) – Pressure Sealed Bonnet
  • OS & Y type, Standard Bore/ Full Bore, Flexible Wedge
  • Design Std: API 600/ ANSI B 16.34, Testing Std: API 598
  • Face to Face as per ANSI B 16.10
  • End Connection : Flanges Drilled to ANSI B 16.5 upto size 24”& ANSI B16.47 series A/B for size above 24”, RF Serrated. Ring Joint Facing (RTJ)/ Butt Weld Ends
  • Hand Wheel/ Gear/ Motor Operated
  • NACE as per MR-01-75
Others on Request
  • Large Sizes
  • Design as per API 6D (Through Conduit & Parallel Slide Gate Valve)
  • Locking Arrangement/ Position Indicator/ Stem Cover
  • Extended Spindle/ Bonnet
  • Drain Plugs
  • High Temp./ Cryogenic Service
  • All Exotic Materials (Hastelloy/ Incoloy/ Super duplex)
  • Body: WCB/ A105/ LCB/ LF2/ CF8/ F304/ CF8M/ F316/ Duplex
  • Trim : 13% Cr/ Stellited/ SS304/ SS316/ Duplex
  • Gasket : Sp. wound SS 304 / 316 with Graphoil / PTFE filler / PTFE
  • Gland Packing : Graphoil / Expanded Graphite/ PTFE
