Flanged Electromagnetic Flow Meter for Accurate Liquid Measurement
Dutco Tennant LLC supplies the MUT2200EL electromagnetic flowmeter, a robust flanged electromagnetic flow sensor engineered for accurate and stable fluid flow measurement in demanding environments. Designed for water and industrial process applications, this sensor delivers extended linearity performance, allowing precise measurement across a wide flow range without compromising accuracy at low or high velocities.
Its fully welded and potted construction ensures long service life, while the IP68 protection rating makes it suitable for buried or permanently submerged installations. The sensor supports bidirectional flow measurement and is available in multiple lining and electrode material options to match varying fluid characteristics and site conditions.
The MUT2200EL can be paired with compatible converters for seamless integration into monitoring, control, and SCADA systems. Ideal for municipal water networks, wastewater treatment, irrigation systems, and industrial facilities, it provides dependable measurement performance that supports operational control, leakage management, and long-term system efficiency.
Industrial Electromagnetic Water Flow Meter System
- Measurement Principle - Operates on Faraday’s electromagnetic induction principle
- Flanged Design - Engineered for pipeline-integrated installation
- No Moving Parts - Ensures negligible pressure drop and low maintenance
- Water Applications - Suitable for potable and wastewater systems
- Low Flow Accuracy - Performs reliably at night and seasonal flows
- Signal Stability - Accelerated flowtube enhances measurement quality
- Process Reliability - Delivers stable and repeatable flow data
Technical Features And Advantages Of Our Electronic Flowmeter
- Measuring Principle - Electromagnetic measurement based on Faraday’s Law with no moving components
- Bi-Directional Measurement - Accurate flow detection in both forward and reverse directions
- Low Flow Sensitivity - High accuracy even at very low velocities and night flow conditions
- Pressure Integrity - Negligible pressure loss due to unobstructed full-bore design
- Structural Construction - Fully welded and potted sensor body for enhanced durability
- Ingress Protection - IP68 rated for submerged or underground installations
- Material Options - Flowtube and flange materials available in corrosion-resistant configurations
- Standards Compliance - Certified for potable water and custody transfer applications
- Installation Flexibility - Reduced straight pipe requirements for compact installation layouts
Types
Standard Flanged Electromagnetic Flowmeter
A full-bore flanged electromagnetic flow meter designed for direct pipeline installation in municipal and industrial systems.
- Suitable for municipal and industrial networks
- Stable performance across varying flow rates
- Compatible with remote or compact converters
Remote Converter Configuration
A split configuration where the sensor and transmitter are installed separately to suit challenging site conditions.
- Flexible field mounting
- Simplified maintenance access
- Suitable for harsh or restricted environments
Compact Integrated Flowmeter
An integrated flow meter electromagnetic solution combining sensor and converter in a single housing for streamlined installation.
- Space-saving installation
- Simplified wiring and commissioning
- Ideal for plant and skid-mounted systems
Standout Features & Benefits
Measurement Stability
- Maintains consistent accuracy over time
- Resistant to mechanical wear
- Supports long-term calibration integrity
Hydraulic Efficiency
- Full-bore design prevents flow obstruction
- Eliminates pressure drop concerns
- Suitable for gravity and pumped systems
Industrial Durability
- Designed for buried and submerged installations
- Resistant to corrosion and environmental stress
- Reliable in demanding utility environments
Operational Reliability
- No moving parts reduces maintenance
- High repeatability across varying loads
- Supports automated monitoring systems
Application Areas
Municipal Water Distribution
- Measures potable water flow accurately
- Supports district metering and loss detection
- Enhances network performance monitoring
Wastewater Treatment Plants
- Monitors influent and effluent flows
- Performs reliably under variable conditions
- Improves process control accuracy
Industrial Process Systems
- Used for conductive process liquids
- Ensures consistent flow validation
- Supports production efficiency
Irrigation & Water Management
- Measures agricultural and district flows
- Operates effectively at low velocities
- Maintains hydraulic efficiency
