Dutco Tennant is proud to introduce the ARMOR-GRIP® Suspension (AGS), an advanced and energy-efficient conductor hardware solution designed to optimize the performance and longevity of high-temperature conductors in power transmission systems.

Dutco will be showcasing the Conductor Support System at the Middle East Energy Exhibition (MEE) 2025 in Dubai, where energy professionals will have the opportunity to discover its unique features and specifications.

This innovative suspension system effectively addresses critical challenges such as wind-induced stresses, aeolian vibration, and galloping, ensuring reliable and efficient energy transmission even in the harshest conditions.

What is ARMOR-GRIP® Suspension (AGS)?

The ARMOR-GRIP® Suspension (AGS) is a high-performance suspension system designed to protect and support aluminum conductors at suspension points.

Engineered with cutting-edge materials and technology, it offers unparalleled durability, reducing wear and tear on conductors and minimizing maintenance costs over time.AGS effectively mitigates the stresses that occur due to environmental factors like wind, ice, and temperature variations.

It is also well-suited for high-temperature conductor suspension, ensuring optimal performance even in demanding thermal conditions.

 Additionally, AGS provides excellent vibration damping for power lines, reducing the risk of fatigue damage caused by aeolian vibration. This makes it an ideal solution for applications in regions with extreme conditions, ensuring a smooth and stable transmission of electrical power.

Key Features

  • Durable Rubber Inserts with Strong Aluminum Support:

The suspension system uses special neoprene inserts (a type of flexible rubber) that are reinforced with strong aluminum alloy. These inserts absorb and spread out the pressure and stress that build up on the conductors. This helps protect the conductors, making them last longer and reducing the risk of damage.

  • Minimal Compressive Load Design:

The aluminium strap design ensures that the compressive load on conductors is minimized, allowing for optimal performance under various load conditions. This reduces the risk of conductor fatigue and damage over time.

  • Two Temperature Variants:

The ARMOR-GRIP Suspension comes in two temperature variants to cater to different operational environments:

    • Standard Model: Rated for continuous operation up to 200°C.
    • High-Temperature (HT) Model: Rated for continuous operation up to 250°C, providing enhanced durability for high-temperature applications.



  • PARROT-BILL® Rod Ends:

The system includes PARROT-BILL® rod ends, which are specially designed for Extra High Voltage (EHV) systems (345 kV+), ensuring that AGS can be used in large-scale and high-voltage power transmission projects.


  • Compatibility with PLP Attachment Hardware:

The ARMOR-GRIP Suspension is fully compatible with PLP’s standard attachment hardware, such as the YP-5910 yoke plate, making it easy to integrate into existing power transmission systems.

Technical Specifications

Parameter

Specification

Unbalanced/Slip Load

20% of conductor's rated breaking strength

Maximum Line Angle

30° (single suspension), 60° (double suspension)

Operating Temp Range

-40°C to +200°C (Standard), -40°C to +250°C (HT)

Rod Alignment Tolerance

±2" (≤230 kV), ±0.75" (≥345 kV)

Color-Coded Identification

Easy-to-read color coding system for quick identification during installation and maintenance

Components:

  • Neoprene Inserts: Pre-marked for easy installation alignment.
  • Precision-Molded Support Rods: Non-interchangeable, ensuring secure and accurate installation.
  • Housing + Strap: Provides robust support and stability.
  • Bolts, Lock Washers, and Lock Nuts: Ensures secure attachment to suspension points.

Conductor Compatibility

The ARMOR-GRIP Suspension is designed to accommodate a wide range of conductor sizes and types, ensuring flexibility across different power transmission projects.

It is compatible with ACSR, AAAC, and other aluminium conductors, making it suitable for various applications, including overhead transmission lines and distribution systems.

Here are some of the key conductor sizes and rod specifications:

Range No.

Diameter (in/mm)

Rod Specifications

Color Code

5156

0.304-0.315" / 7.72-8.00mm

10 rods, 26" long

Brown

5165

0.435-0.450" / 11.03-11.43mm

11 rods, 36" long

Blue

5130HT

1.091-1.118" / 27.70-28.40mm

12 rods, 82" long

Yellow

Why Choose ARMOR-GRIP® Suspension?

  • Reliability: Designed for extreme environments, ARMOR-GRIP Suspension offers reliable protection for conductors, preventing issues like sagging, vibration, and galloping.

  • Long-Lasting Performance: With its robust design and advanced materials, AGS ensures a longer operational life, reducing maintenance needs and enhancing the efficiency of power transmission networks.
  • Enhanced Safety: ARMOR-GRIP Suspension improves the safety and stability of high-voltage transmission lines by reducing the risk of conductor failure and enhancing overall system reliability.
  • Efficiency in Harsh Conditions: Whether in high-temperature zones or regions prone to wind and ice loads, AGS provides optimal conductor performance, ensuring continuous, smooth electrical transmission.

For those seeking the highest quality solutions in power transmission, Dutco Tennant is your trusted supplier for the ARMOR-GRIP® Suspension.

With a reputation for delivering reliable and durable products, Dutco Tennant ensures that your power transmission systems remain efficient and secure.
