Spectrophotometer – UV-Visible Measurement for Routine Laboratory Analysis
The benchtop UV Vis Spectrophotometer provides quantitative measurement across the ultraviolet and visible regions of the spectrum, covering wavelengths from 198 to 1000 nm. It supports absorbance, percentage transmittance and concentration measurements, giving laboratories one instrument for a variety of routine analytical procedures.
A xenon flash lamp supplies the light source across the UV-visible range, while the optical system is independently housed to help protect it from environmental contamination. With a wavelength resolution of 1 nm and wavelength accuracy of ±2 nm, the instrument supports consistent measurements for laboratory testing and sample evaluation.
The system combines simple operation with fast warm-up, low drift and multiple measurement modes, making it useful for technicians, students and laboratory personnel carrying out regular photometric analysis. As a UV Visible Spectrometer, it can be incorporated into workflows ranging from quality checks to environmental sample testing.
Dutco Tennant supplies UV-visible spectrophotometers for laboratories requiring reliable absorbance, transmittance and concentration measurement. The UV Vis Spectrophotometer is suitable for education, quality control, environmental and clinical analysis where straightforward photometric testing is required.
Broad Wavelength Coverage for UV & Visible Analysis
- 198-1000 nm Wavelength Range – Covers both ultraviolet and visible regions for a broad selection of laboratory measurements.
- 1 nm Wavelength Resolution – Allows precise wavelength selection throughout the operating range.
- ±2 nm Wavelength Accuracy – Supports consistent positioning at the selected analytical wavelength.
- Xenon Flash Lamp – Provides illumination across the complete UV-visible range.
- 8 nm Spectral Bandwidth – Operates at 8 nm bandwidth, narrowing to 6 nm over the UV range.
- UV & Visible Measurements – Supports UV and visible measurements across a range of compatible laboratory applications.
Flexible Measurement Modes for Diverse Laboratory Analysis
- Absorbance Measurement – Covers an absorbance range from -0.300 to 1.999 A.
- Transmittance Measurement – Provides readings from 0 to 199.9%T.
- Concentration Measurement – Supports concentration values from -300 to 1999 using calibration with a standard or factor.
- Multiple Concentration Units – Measurements can be expressed using %, ppm, M, g/L and mg/L.
- Simple Calibration – Concentration analysis can be performed using a blank with a single standard or entered factor.
- Laboratory Versatility – The combined modes make the unit more flexible than a basic Visible Spectrophotometer limited to fewer measurement functions.
Types
The instrument is offered in voltage-specific configurations while maintaining the same principal UV-visible measurement capabilities. Selection primarily depends on the electrical supply available at the installation location.
230 V Benchtop UV/Visible Spectrophotometer
The 230 VAC configuration is suitable for laboratories operating from a 230 V, 50 Hz electrical supply and provides the complete 198-1000 nm measurement range.
- Power supply: 230 VAC, 50 Hz
- Wavelength range: 198-1000 nm
- Xenon flash lamp
- Absorbance, transmittance and concentration modes
- Suitable as a Visible Spectrophotometer Dubai solution where 230 V laboratory power is standard.
115 V Benchtop UV/Visible Spectrophotometer
A 115 VAC version provides the same principal optical specifications for laboratories operating with a 115 V, 60 Hz supply.
- Power supply: 115 VAC, 60 Hz
- Wavelength range: 198-1000 nm
- ±2 nm wavelength accuracy
- 8 nm spectral bandwidth, 6 nm in the UV range
- Suitable for facilities using 115 V laboratory infrastructure.
Absorbance Measurement Configuration
Absorbance mode determines how much light is absorbed by the sample at the selected wavelength.
- Range from -0.300 to 1.999 A
- Resolution of 0.001 A
- Suitable for quantitative concentration-related analysis
- Useful for chemical, environmental and biological laboratory testing.
Transmittance Measurement Configuration
Transmittance mode measures the proportion of incident light passing through the sample.
- Range from 0 to 199.9%T
- Resolution of 0.1%T
- Suitable for optical transmission measurements
- Provides an additional analytical mode within the UV Visible Spectrometer
Concentration Measurement Configuration
Concentration mode converts photometric results into concentration values using a calibration standard or factor.
- Concentration range from -300 to 1999
- Calibration using a blank plus single standard or factor
- Units include ppm, M, g/L and mg/L
- Useful for routine quantitative laboratory analysis.
Standout Features & Benefits
UV-to-Visible Wavelength Coverage
- One instrument covers the 198-1000 nm region.
- Allows laboratories to perform both UV and visible measurements.
- Reduces the need for separate instruments for many routine photometric procedures.
- Provides broader functionality than a visible-only system.
Stable Optical Performance
- The optical system is independently housed and isolated from the main instrument structure.
- Lenses help protect internal optics from environmental contamination.
- Fast warm-up and low drift support stable routine measurements.
- These characteristics are valuable for laboratories requiring dependable UV Spectrophotometers.
Multiple Photometric Measurements
- Measures absorbance, transmittance and concentration.
- Allows one instrument to support different testing methods.
- Concentration can be calculated from a standard or entered factor.
- Makes the instrument suitable for routine quantitative analysis rather than single-purpose measurement.
Xenon Flash Lamp Technology
- Xenon illumination covers both ultraviolet and visible wavelengths.
- Supports operation across the full 198-1000 nm measurement range.
- Eliminates the need to switch between separate UV and visible lamps within this instrument configuration.
- Supports reliable operation of theVisible Spectrophotometer across varied wavelengths.
Data & Instrument Connectivity
- Provides RS232 serial interfacing.
- Includes analogue output capability.
- Allows measurement information to be connected with compatible external equipment or data systems.
- Supports integration into established laboratory workflows.
Compact Benchtop Format
- Dimensions are approximately 365 × 272 × 160 mm.
- Instrument weight is approximately 6 kg.
- Suitable for routine placement on laboratory benches without requiring extensive installation space.
- Provides a practical laboratory option for electrochemistry organisations evaluating Spectrophotometer Suppliers.
Application Areas
Water & Environmental Analysis
- Suitable for photometric analysis of environmental samples using compatible analytical methods.
- Concentration mode can display results in units including ppm and mg/L.
- Can support selected water-quality testing procedures where UV-visible measurement forms part of the analytical method.
- Provides useful functionality alongside a laboratory Water Analyzer workflow.
Quality Control Laboratories
- Supports routine comparison of samples against defined photometric specifications.
- Absorbance and transmittance modes provide different approaches to product and material evaluation.
- Suitable for regular measurement where repeatable analytical procedures are required.
Educational Laboratories
- Straightforward measurement modes make the instrument suitable for teaching UV-visible spectroscopy principles.
- Students can work with absorbance, transmittance and concentration measurements.
- Broad wavelength coverage supports different chemistry and analytical science experiments.
Clinical Analysis
- The instrument is identified for clinical analysis applications where compatible spectrophotometric methods are used.
- Concentration measurements support quantitative laboratory procedures.
- UV-visible wavelength coverage accommodates different photometric assays.
Chemical & Research Laboratories
- Useful for analysing substances that absorb radiation within the UV-visible spectrum.
- Supports quantitative measurements during research and method development.
- Adjustable wavelength selection allows testing according to compound-specific analytical methods.
Routine Absorbance & Transmission Testing
- Suitable for samples requiring absorbance or percentage transmittance measurements.
- 1 nm wavelength resolution allows specific analytical wavelengths to be selected.
- Useful across research, testing and general analytical laboratories.
Laboratory Spectrophotometry in Dubai & UAE
- The 230 V configuration is compatible with commonly used laboratory electrical infrastructure in the region.
- Dutco Tennant LLC supports laboratories seeking Visible Spectrophotometer Dubai solutions for environmental, educational, quality-control and research applications.
- Organisations evaluating Spectrophotometer Suppliers can select the instrument based on wavelength range, measurement modes, photometric performance and laboratory application requirements.
